Silicon Wafer

Prime wafers are the foundation of modern semiconductor manufacturing. With strict control over flatness, particle levels, and resistivity, they provide the precision needed for chip fabrication.

Dust-free wafers are a practical, low-cost solution for keeping semiconductor equipment clean, calibrated, and stable. They make sure that before high-value product wafers are processed, the tools

Dummy wafer is a fundamental, low-cost tool used to maintain, calibrate, and stabilize multi-million-dollar semiconductor manufacturing equipment. They ensure that by the time a high-value product

The N-Type M12 Monocrystalline Silicon Wafer adopts a large pseudo square 210×210 mm format (φ295 mm diameter), increasing the active area and boosting power output for high-efficiency PV modules.

The N-Type M2 Monocrystalline Silicon Wafer features a quasi-square 156.75×156.75 mm design with rounded corners, balancing compatibility with standard module layouts and optimized light capture.

Optimized for high-efficiency solar applications, the N-Type M6 Monocrystalline Silicon Wafer features a pseudo-square 166×166 mm design with superior material properties. Manufactured using CZ

The N-Type G1 Monocrystalline Silicon Wafer features a full square 158.75×158.75 mm design, maximizing light exposure and module efficiency. Manufactured using the CZ method with phosphorus doping,

This specification defines N-Type Monocrystalline Silicon Wafers (Size M10) for advanced solar cells. Produced via the Czochralski method with Phosphorus doping, the wafers feature low oxygen

M10 with dimension of 182mmx182mm monocrystalline silicon solar wafer with diameter of 247mm can make higher power solar cells.

182mmx182mm M12 monocrystalline silicon solar wafer with diameter of 247mm can make higher power solar cells.

P-type monocrystalline M4 wafer with dimension of 161.7mm x 161.7mm.

M4 P-type monocrystalline wafer is 161.7mm x 161.7mm.
