Quick Details
Condition: New | Brand Name: DS New Energy |
Place of Origin: Zhejiang, China (Mainland) | Application: Room |
Power Source: Solar | Type: Split Wall Mounted Air Conditioners |
Cooling/Heating: Cooling/Heating | Certification: CB, CE, EMC, RoHS, SASO |
Capacity (btu): 9000 | Power (W): 630 |
Voltage (V): 220 | Model Number: KFR-26GW/BPACDC-TWA1 |
Color: White | Product Name: AC DC Hybrid solar air conditioner |
Function: Air conditioning | Refrigerant: R410A |
Power supply: 220-240V/1Ph/50Hz, DC 50-350V | Cooling capacity: 9000btu |
Product Description
The DC AC Hybrid Solar Inverter technology allows you to harness the renewable clean and free energy from the sun to help you run Air Conditioning unit. You could save up to 97% on your mains power usage with the solar hybrid system, plus it’s easy to install and use so you can get started on saving money and lowering your energy cost with no hassle. The solar panels (sold separately) will be wired directly into the outdoor unit by your installer, this means no addition invertor is required. Once the system is set up, simply switch on and enjoy. The system will automatically pull from the solar panels or the grid depending on the current sunshine levels, you’ll enjoy uninterrupted heating or cooling as the system changes seamlessly with no input required from the user.
Product show
Overview
The AC/DC hybrid solar air conditioner is designed for keeping the inside air conditioning running all day but no costs in energy. The power from the solar panels supply directly to indoor & outdoor fan motor and compressor. When the solar power is not sufficient, the system automatically switches to operate from utility grid power.
The AC/DC hybrid solar air conditioner don’t require batteries, and only a few PV panels to deliver big savings. During the day, when air conditioning is needed the most, you can operate this unit up to 100% by solar panel.
Like all DC-Inverter air conditioners, the HYBRID compressor runs on AC and DC power with the Intelligent Power Management technology. This system can also accept DC power directly from solar panels, without needing an inverter, controller, or batteries. The solar DC power directly replaces an equivalent amount of AC power from utility grid and can cut daytime energy costs for air conditioning or heating by up to 80-90%.
Key features
• Solar Power saving energy bill
• Compatible with 50Hz and 60Hz AC power
• Runs on solar power & AC power
• 9,000 BTU Cooling & 10,000 BTU Heating
• Plug-and-play solar connection
• No batteries required
Structure
The AC/DC hybrid solar air conditioner system is mainly composed of indoor unit, outdoor unit, solar panel, PV cables and brackets:
Working Principle
The HYBRID compressor runs on AC and DC power with the Intelligent Power Management technology. This system can also utilize DC power directly from solar panels, without needing an inverter, controller, or batteries. The solar DC power directly replaces an equivalent amount of AC power from utility grid and can cut daytime energy costs for air conditioning or heating by up to 80-90%.
System infortion
AC DC Hybrid Solar Air Conditioner | ||||
Solar Air Conditioner | 9000btu | 12000btu | 18000btu | 24000btu |
Solar PV Panel | 4pcs, 32V, 300W | 4pcs, 32V, 300W | 8pcs, 32V, 300W | 8pcs, 32V, 300W |
3pcs panels in series,2groups in parallel | 2pcs panels in series,4groups in parallel | |||
Air conditioner technical data
Model | KFR-26GW/BPACDC-TWA1 | KFR-35GW/BPACDC-TWA1 | KFR-50GW/BPACDC-TWA1 | KFR-70GW/BPACDC-TWA1 | ||
Power supply | AC | Ph-V-Hz | 1Ph/220-240V/50-60Hz | |||
DC | V | 50-350V | ||||
Cooling | Rated Capacity | W | 2600 (1000-3500) | 3500 (1000-4100) | 5275 (1200-6000) | 7000 (2500-8200) |
Btu/h | 9000 (3400-12000) | 12000 (3400-14000) | 18000 (4100-20400) | 24000 (8500-28000) | ||
Power Input | W | 630 (200-980) | 860 (190-1250) | 1550 (185-2000) | 2050 (450-3300) | |
Heating | Rated Capacity | W | 3800 (800-4000) | 4300 (1000-4500) | 6200 (1200-6800) | 7800 (2000-9000) |
Btu/h | 13000 (2700-13400) | 14600 (3400-15300) | 21000 (4100-23000) | 26600 (10200-30800) | ||
Power Input | W | 1030 (160-1300) | 1080 (150-1700) | 1650 (220-2500) | 2350 (390-3500) | |
Indoor air flow (Turbo/Hi/Mi/Lo) | m3/h | 580/520/440/370 | 650/620/500/400 | 1020/1000/800/700 | 1200/1150/850/740 | |
Indoor noise level (Turbo/Hi/Mi/Lo) | dB(A) | 41/39/35/27 | 42.5/42/37/29 | 46/46/42/35 | 50/50/45/39 | |
Indoor unit | Dimension(W*D*H) | mm | 823*300*244 | 823*300*244 | 1150*300*260 | 1150*300*260 |
Packing(W*D*H) | mm | 890*360*300 | 890*360*300 | 1230*360*320 | 1230*360*320 | |
Net/Gross weight | Kg | 10.8/13 | 10.8/13 | 14/18 | 15/18.5 | |
Outdoor unit | Dimension(W*D*H) | mm | 800*325*550 | 800*325*550 | 800*325*550 | 912*375*712 |
Packing(W*D*H) | mm | 900*400*610 | 900*400*610 | 900*400*610 | 1040*465*768 | |
Net/Gross weight | Kg | 30/34 | 32.5/36.5 | 35.5/40 | 51/61 | |
Refrigerant type | R410A | R410A | R410A | R410A | ||
Operation temperature | ℃ | 16-32 | ||||
Ambient temp(cooling/heating) | ℃ | 16-55/-20-31 | ||||
Application area | m2 | 8-15 | 15-20 | 20-30 | 32-42 | |
Loading capacity(20GP/40HQ) | set | 80/210 | 80/210 | 70/180 | 50/125 | |
Details
1. AC/DC hybrid solar air conditioner:
• Compatible with 50Hz and 60Hz AC power
• Runs on solar power & AC power
• 12,000 BTU Cooling & 13,000 BTU Heating
• Plug-and-play solar connection
• No batteries required
2. Solar panel:
• Long lifetime: ≥25 years; Less power decrease.
• Highest conversion efficiency of 18.3% solar cells.
• Anti-reflecting coating and high transmission rate glass and mechanical strength.
• High quality EVA and TPT to prevent destroying and water.
• Good performance of preventing from atrocious weather such as wind and hails.
