Product Introduction:

For more generation in the same footprint, PERC has been naturally upgraded to bifacial PERC. On this basis, bifacial PERC is also becoming an important route in the development of the technology. The commonly used manufacturing technology for bifacial PERC cell is to change the printing process of the PERC single-sided cell, and changing the rear surface from whole aluminum layer to a local aluminum layer. This allows incidental light on the rear surface to enter the cell from the exposed layer and create photoelectric conversion on both the front and rear sides.

Send Inquiry

Chat Now

Description

Technical Parameters

【Product description】

Bifacial PREC is short for bafacial Passivated Emitter and Rear Cell. It is based on the P type monocrystalline silicon solar wafer.

For more generation in the same footprint, PERC has been naturally upgraded to bifacial PERC.

On this basis, bifacial PERC is also becoming an important route in the development of the technology. The commonly used manufacturing technology for bifacial PERC cell is to change the printing process of the PERC single-sided cell, and changing the rear surface from whole aluminum layer to a local aluminum layer. This allows incidental light on the rear surface to enter the cell from the exposed layer and create photoelectric conversion on both the front and rear sides.

P Type Mono Bifacial Solar Cell

【Process flow】

【Key features】

Double side generation

Higher output power

Excellent low-light performance

Lower temperature coefficient

【Technical Data】

TECHNICAL DATA AND DESIGN		TEMPERATURE COEFFICIENTS AND SOLDERABILITY
Dimension	156.75mm*156.75mm±0.25	TkUoc (%/K)	-0.35
Thickness	190±30 μm	TkIsc (%/K)	+0.06
Front	5 Busbars	TkPMAX (%/K)	-0.358
Back	5 Busbars	Peel Strength Minimum	>1.4N/mm

ELECTRICAL PARAMETERS at STC
No.	Efficiency (%)	Pmpp (W)	Uoc (V)	Isc (A)	FF (%)
1	22.50%	5.50	0.686	9.836	81.51
2	22.40%	5.47	0.685	9.818	81.41
3	22.30%	5.45	0.684	9.805	81.30
4	22.20%	5.43	0.683	9.796	81.18
5	22.10%	5.40	0.682	9.786	80.92
6	22.00%	5.38	0.681	9.772	80.83
7	21.90%	5.35	0.679	9.757	80.71
8	21.80%	5.33	0.678	9.740	80.63
9	21.70%	5.30	0.676	9.728	80.51
10	21.60%	5.28	0.673	9.722	80.67
11	21.50%	5.25	0.672	9.700	80.60
12	21.40%	5.23	0.671	9.680	80.51
13	21.30%	5.20	0.670	9.662	80.40
14	21.20%	5.18	0.669	9.649	80.29
15	21.10%	5.16	0.668	9.640	80.16
16	21.00%	5.13	0.667	9.630	79.89
17	20.90%	5.11	0.666	9.616	79.80
18	20.80%	5.08	0.664	9.601	79.68
19	20.70%	5.06	0.663	9.584	79.59
20	20.60%	5.03	0.661	9.572	79.47
21	20.50%	5.01	0.658	9.566	79.63
