【Product description】
Using a solar irrigation pump saves time, increases production, and is more economically sustainable than any other irrigation method. Whether you have acres of crops, a small backyard garden, or have a desire to live off-grid and supply your own water, using a solar irrigation pump is an investment that will pay off for years to come.
The system is composed of a PV generator, a pump and a solar pump drive.
Benefits
• Pumping of water in for irrigation for drinking water supply in off grid areas, easy installation.
• Farmer can cultivate multiple crops through out the year in off grid areas
• Farmer can save their time spent in collecting and transporting water.
• Lower operation expense compared to diesel pumps
• Zero emission of green house gases.
• Reduced load on national grid.
【Components list】
Typical configuration In Southeast Asia
8.1KW Solar Panel Powered 5.5kKW AC Water Pump | ||
System | Solar AC pump: 5.5kw | |
Solar panel | Type: mono solar panel(poly optional) 15 pcs in a string, 2 string in parallel | 30 Pcs |
Solar AC pump | Pump capacity: 5.5kw,3-phase 380v Flow: Lift distance 102m, water flow 12m3/h | 1 Unit |
Pump inverter | Rated Power: 7.5kw, 3-phase 380v MPPT controller: 200V-700V | 1 Unit |
Solar panel ground rack | Ground rack installation Snow load:1.5kN/m2 | 1 Unit |
Combiner box | 2 inputs 1 output | 1 Unit |
Cables | From solar panel to inverter: 4mm2 PV cable:100M From inverter to pump: 3*4mm2 AC cable:100M | 1 Unit |
Working time: During sunshime time | ||
