Products Description

This solar water pump system is equipped with 336 mono solar panels, a 110kW three-phase AC pump, and a 132kW inverter featuring high MPPT efficiency and protective functions. With a lift capacity of 60 meters and water flow reaching 338m³/h, it is perfectly suited for large-scale irrigation projects, fish farming, and rural water distribution. The system integrates an advanced combiner box for efficient circuit protection and smooth energy transfer, ensuring durability, safety, and long service life while minimizing reliance on diesel or grid electricity.

Components list

194.9KW Solar Panel Powered 110KW AC Water Pump
System Basic Information	Solar AC pump: 110kw System working time: sunsine time	QTY
Solar Panel	Type: mono solar panel(poly optional) Max power : 580w Vmp: 44.02V ; Voc:51.95V; Imp:13.17A ; Front glass: 2.0mm Tempered Terminal block: IP68 with MC4 connector Efficiency performance: 25 years 89.4%, 20 year 92.7%, 10 years 95.4% 14 pcs in a string, 24 string in parallel	336 Pcs
Solar AC pump	Pump capacity: 110kw 3-phase 380v Flow: Lift distance 60m, water flow 338m³/h	1 Unit
Pump inverter	Rated Power:132kw, 3-phase 380v MPPT controller: 500V-750V MPPT effeiceny: 99.8% Protection: Reliable thunderstorm & surge protection	1 Unit
Solar panel ground rack	Ground rack installation Wind load: 55m/s; Snow load:1.5kN/m2 Structure: Anodized Aluminum+stainless steel,Angle adjustable (other type of rack canbe customized as per client's requirement)	1 Unit
Combiner box	24 inputs 1 output	1 Unit
Cable	From solar panel to inverter: 6mm2 PV cable:1600M From inverter to pump: 3*16mm2 AC cable:100M	1 Unit
Working time: During sunshime time
