165.9kW Solar Panel Powered 90kW AC Water Pump System With Heavy-Duty Aluminum Ground Mounting Structure

Product Introduction:

The 165.9kW solar water pump system with a 90kW AC pump is a powerful and eco-friendly solution for large-scale irrigation, farmland water supply, and community projects. Powered by high-efficiency solar panels and advanced inverter technology, it delivers consistent performance while reducing energy costs and carbon emissions.

Send Inquiry

Chat Now

Description

Technical Parameters

Products Description

Designed for high-demand water pumping applications, the 165.9kW solar-powered 90kW AC water pump system combines robust solar panels, a precision-engineered inverter, and a heavy-duty aluminum mounting structure for reliable long-term operation. With a pumping capacity of 972m³/h and a lift height of 20 meters, it is ideal for agriculture, aquaculture, and industrial projects that require large volumes of water. Operating directly under sunlight, this system provides a cost-effective, low-maintenance, and sustainable alternative to traditional diesel or grid-powered pumps, ensuring stable water supply even in remote or off-grid locations.

Components list

165.9KW Solar Panel Powered 90KW AC Water Pump
System Basic Information	Solar AC pump: 90kw System working time: sunsine time	QTY
Solar Panel	Type: mono solar panel(poly optional) Max power : 580w Vmp: 44.02V ; Voc:51.95V; Imp:13.17A ; Front glass: 2.0mm Tempered Terminal block: IP68 with MC4 connector Efficiency performance: 25 years 89.4%, 20 year 92.7%, 10 years 95.4% 13 pcs in a string, 22 string in parallel	286 Pcs
Solar AC pump	Pump capacity: 90kw 3-phase 380v Flow: Lift distance 20m, water flow 972m³/h	1 Unit
Pump inverter	Rated Power:110kw, 3-phase 380v MPPT controller: 500V-750V MPPT effeiceny: 99.8% Protection: Reliable thunderstorm & surge protection	1 Unit
Solar panel ground rack	Ground rack installation Wind load: 55m/s; Snow load:1.5kN/m2 Structure: Anodized Aluminum+stainless steel,Angle adjustable (other type of rack canbe customized as per client's requirement)	1 Unit
Combiner box	22 inputs 1 output	1 Unit
Cable	From solar panel to inverter: 6mm2 PV cable:1400M From inverter to pump: 3*16mm2 AC cable:100M	1 Unit
Working time: During sunshime time
