Products Description
This high-capacity solar water pump system integrates 504 mono solar panels, a 160kW three-phase AC pump, and a 185kW inverter with high MPPT efficiency to ensure stable power conversion. It delivers a lift height of 55 meters with a water flow of up to 529m³/h, making it ideal for agricultural irrigation, aquaculture, and municipal water supply projects. Designed with a durable ground rack structure resistant to strong winds and heavy snow, the system ensures long-term reliability and consistent performance, supporting eco-friendly and cost-effective water management in off-grid and rural areas.
Components list
| 292.3KW Solar Panel Powered 160KW AC Water Pump | ||
| System Basic Information |
Solar AC pump: 160kw System working time: sunsine time |
QTY |
| Solar Panel | Type: mono solar panel(poly optional) Max power : 580w Vmp: 44.02V ; Voc:51.95V; Imp:13.17A ; Front glass: 2.0mm Tempered Terminal block: IP68 with MC4 connector Efficiency performance: 25 years 89.4%, 20 year 92.7%, 10 years 95.4% 14 pcs in a string, 36 string in parallel |
504 Pcs |
| Solar AC pump | Pump capacity: 160kw 3-phase 380v Flow: Lift distance 55m, water flow 529m³/h |
1 Unit |
| Pump inverter | Rated Power:185kw, 3-phase 380v MPPT controller: 500V-750V MPPT effeiceny: 99.8% Protection: Reliable thunderstorm & surge protection |
1 Unit |
| Solar panel ground rack | Ground rack installation Wind load: 55m/s; Snow load:1.5kN/m2 Structure: Anodized Aluminum+stainless steel,Angle adjustable (other type of rack canbe customized as per client's requirement) |
1 Unit |
| Combiner box | 18 inputs 1 output 2 inputs 1 output |
2 Unit 1 Unit |
| Cable | From solar panel to inverter: 6mm2 PV cable:2200M From inverter to pump: 3*16mm2 AC cable:100M |
1 Unit |
| Working time: During sunshime time | ||
Solar Water Pump
Solar Water Pump
Solar Water Pump
