DSBN 32-50
High Efficiency single-glass N-type solar module
DSBN32-50W High efficiency dual-glass bifacial N-type solar module
10 Year Product Warranty15 Year Linear Power Warranty0.41% Annual Degradation Over 15 years
Ultra-light
Glass-free lightweight construction reduces roof loadwhile enabling easier transportation, handling, andinstallation.
Fast-Installation
Adhesive mounting requires no roof penetration, reduc-ing installation time while protecting roof waterproofperformance.
Sealing with PID
Superior PID resistance ensures stable power output andreliable long-term performance in harsh environments.
Long-Term Durability
Designed for reliable performance under demandingenvironmental conditions.
CERTIFICATION
IEC 61215, IEC 61730, UL 61730 ISO9001:2015: ISO Quality Management System
ISO14001: 2015: ISO Environment Management System
ISO45001: 2018: Occupational Health and Safety
IEC62941: Guideline for module design qualification and type approval
MECHANICAL PARAMETERS
| Solar Cell | N-Type |
| No. of Cells | 32 (2×16) |
| Module Dimensions | 635×400×30mm |
| Weight | 2.4kg |
| Front Glass | 3.2mm ultra-white cloth tempered glass |
| Frame | Anodized |
| J-box | IP 65 |
| Output Cables | PVCQ006+2.5mm2+900mm+mc4,or Customized Length |
| ndividually wrapped | 5184pcs/40HQ |
ELECTRICAL PARAMETERS
| DSBN 50 | STC | NOCT |
|---|---|---|
| Maximum Power (Pₘₐₓ) | 50 | 37 |
| Maximum Power Voltage (Vₘₚ) | 19.81 | 18.76 |
| Maximum Power Current (Iₘₚ) | 2.53 | 1.99 |
| Open-circuit Voltage (Vₒc) | 23.52 | 22.28 |
| Short-circuit Current (Iₛc) | 2.58 | 2.08 |
| Module Efficiency (%) | 19.69 | |
| Operating Temperature | -40℃ ~ +85℃ | |
| Maximum System Voltage | 600/1000V DC (IEC) | |
| Maximum Series Fuse Rating | 15 A | |
| Power Tolerance | 0~3% | |
| Temperature Coefficient Power (Pm) | -0.29%/℃ | |
| Temperature Coefficient Voltage (Voc) | -0.25%/℃ | |
| Temperature Coefficient Current (Isc) | 0.045%/℃ | |
| Nominal Module Operating Temperature(NOCT) | 45±2℃ | |
PACKAGE
