【Product introduction】
|
Cell |
Mono |
|
No. of cells |
144(6×24) |
|
Rated Maximum Power(Pmax) |
455W |
|
Maximum Efficiency |
20.6% |
|
Junction Box |
IP68 |
|
Maximum System Voltage |
1500V DC |
|
Operating Temperature |
-40℃～+85℃ |
【Product description】
440W high power solar panel powered by 144 pieces of high-efficiency half-cells, this series of high-performance modules provides the most cost-effective solution for lowering the LCOE of any PV systems large or small.Half-cut technology are literally normal solar cells that have been cut in half.
This family solar panel employed half-cell (half-cut) technology is encapsulated with 144 half-cells and 6x24 layout. With power up to 410W this family solar panel help to lower BOS cost.
【Key features】
【Dimension of PV module】
【Electrical data at STC】
|
Rated Maximum Power(Pmax) [W] |
435 |
440 |
445 |
450 |
455 |
|
Open Circuit Voltage(Voc) [V] |
49.1 |
49.2 |
49.4 |
49.6 |
49.8 |
|
Maximum Power Voltage(Vmp) [V] |
40.8 |
41 |
41.2 |
41.4 |
41.6 |
|
Short Circuit Current(Isc) [A] |
11.36 |
11.45 |
11.52 |
11.58 |
11.65 |
|
Maximum Power Current(Imp) [A] |
10.66 |
10.73 |
10.8 |
10.87 |
10.93 |
|
Module Efficiency [%] |
19.7% |
19.9% |
20.1% |
20.4% |
20.6% |
|
Power Tolerance |
0~+5W |
||||
|
Temperature Coefficient of Isc(α_Isc) |
0.059%/℃ |
||||
|
Temperature Coefficient of Voc(β_Voc) |
-0.298%/℃ |
||||
|
Temperature Coefficient of Pmax(γ_Pmp) |
-0.369%/℃ |
||||
|
STC |
Irradiance 1000W/m², cell temperature 25℃, AM1.5G |
||||
【Electrical data at NOCT and Operating conditions】
|
ELECTRICAL PARAMETERS AT NOCT |
|||||
|
TYPE |
435 |
440 |
445 |
450 |
455 |
|
Rated Max Power(Pmax) [W] |
323.9 |
328.3 |
332.7 |
337.2 |
341.2 |
|
Open Circuit Voltage(Voc) [V] |
45.7 |
45.8 |
46.0 |
46.2 |
46.4 |
|
Max Power Voltage(Vmp) [V] |
37.8 |
38 |
38.2 |
38.4 |
38.6 |
|
Short Circuit Current(Isc) [A] |
9.75 |
9.82 |
9.88 |
9.94 |
10.00 |
|
Max Power Current(Imp) [A] |
8.57 |
8.64 |
8.71 |
8.78 |
8.84 |
|
NOCT |
Irradiance 800W/m², ambient temperature 20℃,wind speed 1m/s, AM1.5G |
||||
|
OPERATING CONDITIONS |
|
|
Maximum System Voltage |
1500V DC(IEC) |
|
Operating Temperature |
-40℃~+85℃ |
|
Maximum Series Fuse |
20A |
|
Maximum Static Load,Front |
5400Pa |
|
Maximum Static Load,Back |
2400Pa |
|
NOCT |
45±2℃ |
|
Application Class |
Class A |
【Current-voltage curves】
【Mechanical data】
|
weight |
29.5kg±3% |
|
Dimensions |
2131±2mm×1052±2mm×35±1mm |
|
Cable Cross Section Size |
4mm2 |
|
No. of cells |
144(6x24) |
|
Junction Box |
IP68, 3 diodes |
|
Connector |
QC 4.10-35 |
|
Cable Length(Including Connector) |
300mm(+)/300mm(-) |
|
Packaging Configuration |
30 Per Pallet |
【Certification】
【Warranty】
