【Product introduction】
|
Cell |
Mono |
|
No. of cells |
144(6×24) |
|
Rated Maximum Power(Pmax) |
550W |
|
Maximum Efficiency |
21.3% |
|
Junction Box |
IP68 |
|
Maximum System Voltage |
1000V/1500V DC |
|
Operating Temperature |
-40℃～+85℃ |
【Product description】
550W high power solar panel Made from 11BB PERC solar cells, this series of high-performance modules provides the most cost-effective solution for lowering the LCOE of any PV systems large or small. Half-cut technology are literally normal solar cells that have been cut in half.
【Key features】
【Dimension of PV module】
【Electrical data at STC】
|
Rated Maximum Power(Pmax) [W] |
525 |
530 |
535 |
540 |
545 |
|
Open Circuit Voltage(Voc) [V] |
49.15 |
49.3 |
49.45 |
49.6 |
49.75 |
|
Maximum Power Voltage(Vmp) [V] |
41.15 |
41.31 |
41.47 |
41.64 |
41.8 |
|
Short Circuit Current(Isc) [A] |
13.65 |
13.72 |
13.79 |
13.86 |
13.93 |
|
Maximum Power Current(Imp) [A] |
12.76 |
12.83 |
12.9 |
12.97 |
13.04 |
|
Module Efficiency [%] |
20.3 |
20.5 |
20.7 |
20.9 |
21.1 |
|
Power Tolerance |
0~+5W |
||||
|
Temperature Coefficient of Isc(α_Isc) |
0.046%/℃ |
||||
|
Temperature Coefficient of Voc(β_Voc) |
-0.277%/℃ |
||||
|
Temperature Coefficient of Pmax(γ_Pmp) |
-0.351%/℃ |
||||
|
STC |
Irradiance 1000W/m², cell temperature 25℃, AM1.5G |
||||
【Electrical data at NOCT and Operating conditions】
|
ELECTRICAL PARAMETERS AT NOCT |
|||||
|
TYPE |
525 |
530 |
535 |
540 |
545 |
|
Rated Max Power(Pmax) [W] |
397 |
401 |
405 |
408 |
412 |
|
Open Circuit Voltage(Voc) [V] |
46.05 |
46.18 |
46.31 |
46.43 |
46.55 |
|
Max Power Voltage(Vmp) [V] |
38.36 |
38.57 |
38.78 |
38.99 |
39.2 |
|
Short Circuit Current(Isc) [A] |
10.97 |
11.01 |
11.05 |
11.09 |
11.13 |
|
Max Power Current(Imp) [A] |
10.35 |
10.39 |
10.43 |
10.47 |
10.51 |
|
NOCT |
Irradiance 800W/m², ambient temperature 20℃,wind speed 1m/s, AM1.5G |
||||
|
OPERATING CONDITIONS |
|
|
Maximum System Voltage |
1000V/1500V DC(IEC) |
|
Operating Temperature |
-40℃~+85℃ |
|
Maximum Series Fuse |
25A |
|
Maximum Static Load,Front |
5400Pa |
|
Maximum Static Load,Back |
2400Pa |
|
NOCT |
45±2℃ |
|
Application Class |
Class A |
【Current-voltage curves】
【Mechanical data】
|
SPECIFICATIONS |
|
|
Cell |
Mono |
|
weight |
28.6kg±3% |
|
Dimensions |
2279±2mm×1134±2mm×35±1mm |
|
Cable Cross Section Size |
4mm2 |
|
No. of cells |
144(6x24) |
|
Junction Box |
IP68, 3 diodes |
|
Connector |
QC 4.10 (1000V) / QC 4.10-35(1500V) |
|
Cable Length(Including Connector) |
1300mm(+)/1300mm(-) |
|
Packaging Configuration |
31 Pcs/Pallet, 620 Pcs/40ft Container |
【Certification】
【Warranty】
