What is 100% dc split solar ac
This is the perfect combination of direct current solar energy and direct current variable frequency air conditioning --48V direct current variable frequency solar air conditioning, making the best use of solar energy.
The 48V dc solar inverter air conditioning system is composed of solar photovoltaic panels, MPPT solar charger, gel battery pack and dc inverter ac (indoor and outdoor).
How to work
In Sunshine day, the solar panel produce the DC48V power to charge the battery to store the power, at the same time provides the power to DC48V compressor and fan motor, then cooling or heating the room.
The indoor motor, compressor, outdoor motor in the new generation 100% solar air conditioner system all adopt brushless DC motor, greatly improve the stability and efficiency of the system.
Features:
1. Can work 100% by solar panels, 100% energy saving.
2. Complete system driven by 48V directive current power
3. NO DC/AC power inverter required, without energy loss
4. 48V directive current permanent magnet compressors
5. Lowest energy loss, EER > 6
6. Eco-friend R134a CFC free refrigerant
Advantages and Disadvantages:
Can work 100% by solar power, need not AC electricity, no electricity bill
But price is very high.
Hot sale Area:
1.Area with abundant sunshine (Africa, Middle-east, South Asia, Latin America)
2.Area with expensive electricity power supply
3.Area with often power failures
4.Small islands (Caribbean area etc)
5.Area without AC power supply
Working Principle
The HYBRID compressor runs on AC and DC power with the Intelligent Power Management technology. This system can also utilize DC power directly from solar panels, without needing an inverter, controller, or batteries. The solar DC power directly replaces an equivalent amount of AC power from utility grid and can cut daytime energy costs for air conditioning or heating by up to 80-90%.
System infortion
|
AC DC Hybrid Solar Air Conditioner |
||||
|
Solar Air Conditioner |
9000btu |
12000btu |
18000btu |
24000btu |
|
Solar PV Panel |
4pcs, 32V, 300W |
4pcs, 32V, 300W |
8pcs, 32V, 300W |
8pcs, 32V, 300W |
|
3pcs panels in series,2groups in parallel |
2pcs panels in series,4groups in parallel |
|||
Air conditioner technical data
|
Model |
KFR-26GW/BPACDC-TWA1 |
KFR-35GW/BPACDC-TWA1 |
KFR-50GW/BPACDC-TWA1 |
KFR-70GW/BPACDC-TWA1 |
||
|
Power supply |
AC |
Ph-V-Hz |
1Ph/220-240V/50-60Hz |
|||
|
DC |
V |
50-350V |
||||
|
Cooling |
Rated Capacity |
W |
2600 (1000-3500) |
3500 (1000-4100) |
5275 (1200-6000) |
7000 (2500-8200) |
|
Btu/h |
9000 (3400-12000) |
12000 (3400-14000) |
18000 (4100-20400) |
24000 (8500-28000) |
||
|
Power Input |
W |
630 (200-980) |
860 (190-1250) |
1550 (185-2000) |
2050 (450-3300) |
|
|
Heating |
Rated Capacity |
W |
3800 (800-4000) |
4300 (1000-4500) |
6200 (1200-6800) |
7800 (2000-9000) |
|
Btu/h |
13000 (2700-13400) |
14600 (3400-15300) |
21000 (4100-23000) |
26600 (10200-30800) |
||
|
Power Input |
W |
1030 (160-1300) |
1080 (150-1700) |
1650 (220-2500) |
2350 (390-3500) |
|
|
Indoor air flow (Turbo/Hi/Mi/Lo) |
m3/h |
580/520/440/370 |
650/620/500/400 |
1020/1000/800/700 |
1200/1150/850/740 |
|
|
Indoor noise level (Turbo/Hi/Mi/Lo) |
dB(A) |
41/39/35/27 |
42.5/42/37/29 |
46/46/42/35 |
50/50/45/39 |
|
|
Indoor unit |
Dimension(W*D*H) |
mm |
823*300*244 |
823*300*244 |
1150*300*260 |
1150*300*260 |
|
Packing(W*D*H) |
mm |
890*360*300 |
890*360*300 |
1230*360*320 |
1230*360*320 |
|
|
Net/Gross weight |
Kg |
10.8/13 |
10.8/13 |
14/18 |
15/18.5 |
|
|
Outdoor unit |
Dimension(W*D*H) |
mm |
800*325*550 |
800*325*550 |
800*325*550 |
912*375*712 |
|
Packing(W*D*H) |
mm |
900*400*610 |
900*400*610 |
900*400*610 |
1040*465*768 |
|
|
Net/Gross weight |
Kg |
30/34 |
32.5/36.5 |
35.5/40 |
51/61 |
|
|
Refrigerant type |
R410A |
R410A |
R410A |
R410A |
||
|
Operation temperature |
℃ |
16-32 |
||||
|
Ambient temp(cooling/heating) |
℃ |
16-55/-20-31 |
||||
|
Application area |
m2 |
8-15 |
15-20 |
20-30 |
32-42 |
|
|
Loading capacity(20GP/40HQ) |
set |
80/210 |
80/210 |
70/180 |
50/125 |
|
Packaging and logistics
