【Product description】
This type of amorphous 5V Solar Cell can be integrated into Electronic Pen (or Mouse),Quiz Calculator for book or DVD,Piano book, Music and sound book.
【Quick details】
Open Circuit Voltage [V] | Short Circuit Current [mA] | Voltage @ Pmpp [V] | Current @ Pmpp [mA] |
4.8 | 11 | 3.5 | 10 |
Dimensions (L x W x H): 25 x 14 x 1.8 ±0.3 [mm]
Weight: 3.0 grams
Storage Temperature: -40°C ~ +90°C
Operation Temperature: -40°C ~ +90°C
Product are compliant to the RoHS Norm.
Amorphous 5V Solar Cell
About Amorphous Silicon
Amorphous silicon (a-Si): is an amorphous form of silicon. The unit structure has a single sequence of pin layers. When exposed to sunlight, their power output is greatly reduced. A-Si thin film solar cells are usually found in calculators. A-Si thin film is manufactured in 6 steps. First, a TCO (transparent conductive oxide) layer is coated on the glass substrate as a front contact, and then P1 laser scribing is performed. An a-Si layer is then deposited and then subjected to a P2 laser scribing. Then, the metal conductive layer is brought into contact with the back side of the relevant P3 laser scribe.
【 Front-side and back-side view】
Top View 1 Top View 2
【 Dimensions in millimeters】
Front-side View details Back-side View details
